Frame

The frame adopts an “O” shaped (closed) structure and is welded with steel plates. The steel plates have undergone strict material analysis to ensure the quality. It is designed according to the scientific movement mechanics. The main board and internal stiffeners are reasonably designed to ensure the overall stability of the frame.

Drive Mechanism

The turbine worm reducer and double-chain drive are used to drive the cutter head. The reducer is installed inside the frame to enhance the transmission stability and displacement accuracy. The cutter head is designed with an enlarged cylinder seat and two cylinders, which has can run synchronously and position stably and accurately to avoid the wear of the side sleeve of the cutter head.

Punching Assembly

High-power hollow shaft servo motor is used to output power and the crankshaft is connected to the servo motor as a whole to avoid the misalignment and delay caused by too many connections. The direct-drive punching operation is featured by high stability and fast response speed, and the swing method is adopted. The swing angle is automatically selected according to the punching stroke and process to greatly improve the efficiency.

Feeding Mechanism

The Y-axis is designed with a one-piece connecting plate and the X-axis square tube beam is designed with two guide rails. After tempering treatment, the self-weight of the components is reduced, the operation is more stable and the positioning is more accurate. The guide rails and lead screws are imported from Taiwan and they are assembled according to strict and scientific assembly process. The company is also equipped with advanced laser collimator and laser interferometer to ensure assembly accuracy and effectively improve feeding accuracy and operating speed.

[ { "Bigtit":"Professional Cnc Turret Punching Machine", "title": "High Quality Forming, Tapping & Punching Applications", "pic": "https://shopcdnpro.grainajz.com/category/357848/1723/289a33682661911f9563ba338175066f/%E9%A3%8E%E6%A0%BC%E7%89%B9%E7%82%B9.png", "desc": "The variable dwell capability at the bottom of the stroke provides for high quality forming. Typical operations such as progressive forming, marking, shutters, etc. can be achieved.With roller wheel technology you are not limited to straight geometries but can produce curved and round configurations. Tapping is also possible. " }, { "title": "Rigid Press Frame", "pic": "https://shopcdnpro.grainajz.com/category/357848/1723/0125b4fdd2a4871ad110f99ba445ef00/%E7%B3%BB%E7%BB%9F.png", "desc": "The steel plates have undergone strict material analysis to ensure the quality. It is designed according to the scientific movement mechanics. The main board and internal stiffeners are reasonably designed to ensure the overall stability of the frame. O-type closed integral welding press frame special for servo punch press. " }, { "title": "Motor Oil Cooling Method", "pic": "https://shopcdnpro.grainajz.com/category/357848/1723/e0a79a9f0590b335ffb16c7a55e445a6/%E5%86%B7%E5%8D%B4.png", "desc": "The servo motor is oil-cooled by using the oil cooler, which has the advantages of low temperature rise and high overload capacity. It solves the problem of frequent replacement of coolant in cold areas in winter. " }, { "title": "Flexible Turret Concepts", "pic": "https://shopcdnpro.grainajz.com/category/357848/1723/d0784519cae545250611c618beeb7be0/%E6%A6%82%E5%BF%B5.png", "desc": "STON is compatible with thick turret tooling,the wide variety of specialty tools combined with the programmable ram means the STON can deliver for any application. The auto indexable stations have a dual lead worm structure. The worm gear’s side clearance can be controlled under 0. 001mm and can be adjusted for wear. Permanently engaged auto index drive system reduces errors and avoids downtime. Each station can be fitted with various brand tools, such as Mate and Wilson. " }, { "title": "Advanced Servo System", "pic": "https://shopcdnpro.grainajz.com/category/357848/1723/b3272ff0168faa2c14129aca7f634189/%E7%B3%BB%E7%BB%9F.png", "desc": "Providing energy efficiency, mineral oil does not require, green, Servo control Punching Machine Advanced CNC Servo system with pressure valve to precisely control the speed, volume and pressure of oil flow. To control the RAM stroke distance on both ends, hence the height and depth of each punch becomes programmable with 0. 1mm accuracy. Uniquely designed Machine structure ensures less preventive maintenance The AC punch servo motor can be programmed for various applications. High speed applications. Low noise applications. Forming applications. " } ]
